229-7098 K90 RH Corner Bolt-On Bucket Adapter

Full Description

The 229-7098 K90 Bucket Adapter is a right-hand corner adapter designed for Cat-style K Series ground engaging tool systems. Its bolt-on two-strap configuration mounts to the right corner of a compatible loader bucket edge and provides the supporting interface for a replaceable K90 bucket tip.

The verified reference design has an overall length of approximately 425 mm, a width of 107 mm and two mounting holes spaced 116 mm apart. It is designed for a 32 mm base-edge thickness class, a 22.5-degree edge bevel and a 2-degree corner kickout angle.

Unlike a center adapter, the RH corner configuration is shaped specifically for the right side of the bucket. It must be paired with the correct left-hand adapter where a complete corner set is required. The corresponding left-hand reference is 229-7099.

This aftermarket adapter is suitable for selected wheel-loader and track-loader bucket applications in construction, quarrying, mining, road building and aggregate handling. Custom logo, color, inspection documentation and export packaging are available for overseas distributors and bulk purchasers.

Fitment must be verified using the existing adapter number, left/right position, bucket-edge thickness, bevel angle, mounting-hole size, hole spacing and machine serial number. Machine model alone does not guarantee compatibility.

Key Features

• Replacement reference for 229-7098 / 2297098

• K90 Cat-style K Series configuration

• Right-hand corner position

• Bolt-on two-strap adapter design

• Two mounting holes

• 116 mm mounting-hole spacing

• Designed for a 32 mm base-edge thickness class

• 22.5° edge bevel

• 2° corner kickout angle

• Alloy-steel construction

• Supports compatible replaceable K90 bucket tips

• No field welding required for installation

• Custom logo, color and packaging available

• Dimensional and material inspection available before shipment

Applications

Equipment types:

• Wheel-loader buckets

• Track-loader buckets

• K90-compatible loader bucket systems

• Heavy-duty material-handling buckets

Industries:

• Construction

• Mining

• Quarrying

• Aggregate handling

• Road building

• Sand and gravel operations

• General earthmoving

Referenced models:

963, 963C, 963D, 963K, 973C, 973D, 973K, 950H, 962H, 966G II, 966H, 966K, 966K XE, 966L, 966M, 966M XE, 972G II, 972H, 972K, 972L, 972M, 972M XE and 988H.

Compatibility Notice:
Model references are for identification only. Verify the right-hand position, bucket configuration, machine serial number, 32 mm edge class, 22.5° bevel, mounting-hole size and 116 mm hole spacing before ordering.
