E161-3017 Weld-On Bucket Tooth Adapter for Hyundai R210-Series

Full Description

E161-3017 is a weld-on bucket tooth adapter used in selected Hyundai excavator bucket configurations. It is installed on the bucket lip or cutting-edge structure and provides the mounting interface for a replaceable E161-series tooth point. This product is offered as an aftermarket replacement part and is not represented as an original Hyundai component.

Hyundai R210LC-7 parts-catalog information identifies E161-3017 as an “ADAPTER-TOOTH.” In several bucket configurations, the catalog lists E161-3017 adapters together with E161-3027 tooth points. The same catalog indicates that E161-3017 was used within an earlier machine or bucket serial range, while later configurations use adapter reference 61N6-31320. This serial-number distinction means the two adapter numbers should not be treated as automatically interchangeable.

The photographed part has a tapered front nose with a transverse opening for the applicable tooth-retention system. Two extended mounting straps form a slot around the bucket lip, allowing the adapter to be positioned and welded to the bucket structure. A raised reinforcement section is visible above the mounting area. The cast marking E161-3017 appears on the side, and the exterior has a yellow painted or coated finish.

Market references commonly associate E161-3017 with older Hyundai R200 and R210 excavator bucket systems. The strongest catalog evidence supports selected R210LC-7 bucket configurations. Fitment must be confirmed using the machine serial number, bucket assembly and tooth-system information.

Several lip-slot versions are advertised under related E161-3017 references, including approximately 32 mm, 35 mm and 40 mm variants. Another professional catalog describes a 1¼-inch version. Because the submitted number does not contain a thickness suffix and the photograph has no measurement scale, the required lip thickness cannot be confirmed visually.

Locking-component references also vary between catalogs. Tooth points, pins and retainers are therefore not assumed to be included. Buyers should provide the existing tooth number, pin and retainer style, lip thickness and adapter-slot measurements.

The exact material grade, hardness, heat-treatment method, dimensions and weight have not been independently verified. These specifications should be confirmed using an approved drawing, physical sample or agreed inspection requirements.

This adapter is intended for distributors, importers, bucket repair workshops, construction contractors, mining service companies and fleet-maintenance teams sourcing replacement excavator ground-engaging parts.

Key Features

• E161-3017 cast marking

• Weld-on bucket tooth adapter configuration

• Hyundai E161 tooth-system reference

• Tapered front adapter nose

• Transverse retention opening

• Two mounting straps forming a bucket-lip slot

• Reinforced upper-body structure

• Aftermarket replacement for compatibility-based procurement

Compatible Machine Models

Confirmed catalog application:

• Hyundai R210LC-7 — selected early serial-number and bucket configurations

Additional compatibility references:

• Hyundai R200 series — confirmation required

• Hyundai R210 series — confirmation required

Fitment depends on the machine serial number, bucket assembly, lip thickness, existing tooth system and adapter dimensions. Machine model alone does not confirm compatibility.

Reference Part Numbers

• E161-3017 — Primary reference

• E1613017 — Alternative written format

• E161-3017-AS — Dealer replacement reference; verify specification

• 61N6-31320 — Later bucket-configuration reference; not automatically interchangeable

Associated component:

• E161-3027 — Tooth-point reference

The tooth, pin and retainer are not assumed to be included.

Applications

• Excavator digging buckets

• General construction excavation

• Earthmoving and trenching

• Bucket repair and rebuilding

• Replacement of worn weld-on tooth adapters

• Hyundai E161 tooth-system maintenance
