232-0134 K130 Center Two-Strap Loader Bucket Adapter

The 232-0134 is a K130 center bucket adapter designed for compatible wheel-loader cutting edges. It provides the mounting interface between the bucket base edge and replaceable K130 tips using a vertical retention system.

The reference adapter measures approximately 469 mm in overall length and 178 mm in width, with a 218 mm bottom strap. Industry K Series application guides identify this configuration as a loader two-strap center adapter for a nominal 51 mm base edge. The actual edge thickness, strap clearance and welding geometry must be checked before installation.

This aftermarket adapter is intended for wheel-loader bucket rebuilding, GET replacement and fleet maintenance in construction, aggregate handling, quarrying and heavy loading operations. Compatibility should be verified using the existing part number, adapter dimensions, K130 interface and bucket configuration rather than machine model alone.

Key Features

• Reference part number 232-0134

• K130 K Series interface

• Center loader-bucket position

• Vertical retention system

• Two-strap configuration

• Weld-on installation, subject to product drawing

• Nominal 51 mm base-edge reference

• Approximately 469 mm overall length

• Supports replaceable K130 bucket tips

• Suitable for selected 986H and 988-series loader buckets

• Material and dimensional inspection available by agreement

• Custom marking, color and export packaging options

• Suitable for bucket rebuilding and fleet GET maintenance

Applications

The 232-0134 is intended for the center positions of compatible wheel-loader buckets equipped with a K130 ground engaging tool system.

Typical applications include:

• General production loading

• Aggregate handling

• Quarry loading

• Stockpile management

• Heavy earthmoving

• Sand and gravel operations

• Construction material handling

• Wheel-loader bucket rebuilding

• GET replacement

• Fleet maintenance programs

Compatibility Notice

The CAT reference part is associated with selected:

• 986H wheel loaders

• 988G wheel loaders

• 988H wheel loaders

• 988K wheel loaders

• Compatible bucket assemblies

Bucket configurations can differ within the same machine model. Confirm the existing adapter number, K130 tip system, center position, base-edge thickness and installation dimensions before ordering.
