XS50RC Rock Chisel Tooth with 1060MXS50 Centre Adapter for Hensley XS50 System

Full Description

The XS50RC and 1060MXS50 form part of the Hensley GET XS50 bucket tooth and adapter system. In the photographed arrangement, the XS50RC replaceable rock chisel tooth is mounted on the nose of the 1060MXS50 centre weld-on adapter. Each component has its own part number and can be identified separately during maintenance or replacement.

XS50RC is classified as a rock chisel bucket tooth. Its tapered working profile is intended for digging applications where penetration and concentrated contact at the tooth tip are required. The tooth is installed over a compatible XS50 adapter nose and retained by the specified XS50-series fastening arrangement. The XS50RC marking is visible on the photographed tooth body.

The 1060MXS50 is a centre weld-on adapter for the XS50 tooth system. Published reference information associates it with a 60 mm plate lip and a 50-ton machine class. The adapter is welded to the bucket’s front lip and provides the mounting interface for the replaceable tooth. The 1060MXS50 marking is visible on the rear section of the photographed component.

The tooth, adapter and retention parts perform different functions and should not be treated as a single part number. The photo shows the tooth and adapter in an assembled position, but this does not confirm that both components or the pin assembly are included in every quotation. Buyers should specify whether they require the tooth only, the adapter only, or a quoted set with the required retention components.

Published technical references commonly associate the XS50 system with the XS50PC pin assembly. However, the pin design and inclusion must be confirmed for the supplied parts. Pins and retainers are not included unless separately listed.

Compatibility cannot be determined from the machine model alone. Buckets used on machines of a similar operating class may have different lip thicknesses, bevel angles, adapter layouts or tooth systems. Buyers should check the existing tooth and adapter markings, bucket-lip thickness, adapter nose profile and retention arrangement before ordering.

This aftermarket replacement arrangement is intended for distributors, importers, bucket manufacturers, repair workshops, mining customers and contractors sourcing ground-engaging components. Material grade, hardness, heat treatment, inspection requirements, packaging and supply scope should be agreed during quotation.

Key Features

• XS50RC rock chisel tooth profile

• Hensley GET XS50 system reference

• 1060MXS50 centre weld-on adapter

• Adapter referenced for a 60 mm bucket lip

• Replaceable tooth fitted over a welded adapter

• Visible component markings for identification

• Tooth and adapter available as separately quoted components

• Compatibility checking by part number and bucket dimensions

Compatible Machine Models

Specific machine models have not been confirmed for publication. Compatibility must be checked using the existing tooth and adapter numbers, bucket-lip thickness, adapter profile and retention system.

Reference Part Numbers

• XS50RC — rock chisel tooth

• 1060MXS50 — centre weld-on adapter

• 1060MXS50-60 — market reference for the 60 mm lip configuration

• XS50PC — associated pin assembly; not an equivalent part number

No fully interchangeable OEM cross-reference has been independently confirmed.

Applications

• Excavator bucket digging systems

• Rock and compact-material excavation

• Quarry and construction bucket maintenance

• Replacement of worn bucket teeth

• Bucket fabrication and rebuilding

• Ground-engaging wear-parts supply
