232-0115 K110 Weld-On Two-Strap RH Corner Bucket Adapter

The 232-0115 is a K110-series right-hand corner adapter designed for compatible excavator bucket cutting edges. Its two-strap weld-on construction provides the mounting interface for replaceable K110 bucket tips while supporting the wear-prone right corner of the bucket.

The reference geometry includes a 60 mm base-edge thickness class, a 22.5-degree bevel and a 4-degree corner kickout. Principal dimensions are 446 mm in overall length, 120 mm in width and 294 mm along the bottom strap.

This aftermarket adapter is intended for bucket rebuilding, GET replacement and fleet maintenance programs in earthmoving, civil construction, quarrying and selected mining applications. Compatibility must be verified using the existing part number, adapter orientation, K110 interface, cutting-edge thickness and installation dimensions. Machine model alone is not sufficient for final selection.

Key Features

• Reference part number 232-0115

• K110 / K Series interface

• Right-hand corner configuration

• Two-strap weld-on design

• 60 mm base-edge thickness class

• 22.5° base-edge bevel

• 4° corner kickout

• 446 mm overall length

• No mounting holes

• Supports replaceable K110 bucket tips

• Suitable for bucket rebuilding and GET replacement

• Material inspection and custom marking available by agreement

• Export packaging for bulk B2B orders

Applications

The 232-0115 adapter is designed for the right-hand corner of compatible excavator buckets using a K110 ground engaging tool system.

Typical applications include:

• General excavation

• Heavy earthmoving

• Road and civil construction

• Trenching and site preparation

• Quarry loading

• Aggregate handling

• Abrasive soil conditions

• Selected mining excavation

• Excavator bucket rebuilding

• Fleet GET maintenance programs

Compatibility Notice

The reference part is associated with selected CAT 322, 324, 325, 329, 330, 336, 345 and 350 excavator configurations.

Bucket specifications may differ within the same machine model. Confirm compatibility using the existing adapter number, K110 system, right-hand orientation, base-edge thickness, bevel angle, kickout angle and installation dimensions.
