222-1097 K90 Center Bolt-On Two-Strap Bucket Adapter

Full Description

The 222-1097 K90 Bucket Adapter is a center-position, bolt-on two-strap adapter designed for Cat-style K Series ground engaging tool systems. It mounts over a 40 mm bucket edge with a 22.5-degree bevel angle and provides the supporting interface for compatible K90 replaceable bucket tips.

Its two-strap construction grips both sides of the bucket edge, while the bolt-on design allows replacement without welding. Compared with higher-profile adapter designs, the low-profile structure helps maintain bucket penetration and material flow during loading operations.

This aftermarket adapter is intended for selected wheel-loader and track-loader buckets used in construction, quarrying, mining, aggregate handling and general earthmoving. It can be supplied with customized color, logo and export packaging for distributors, equipment repair companies and fleet operators.

Fitment must not be determined by machine model alone. Before ordering, verify the existing adapter part number, 40 mm edge thickness, 22.5° bevel angle, mounting-hole pattern, bucket configuration and required K90 tip system. Please provide drawings, dimensions or machine serial information if compatibility assistance is required.

Key Features

• Replacement reference for 222-1097 / 2221097

• K90 Cat-style K Series adapter configuration

• Center-position bucket adapter

• Bolt-on installation without field welding

• Two-strap design for stable edge engagement

• Designed for a 40 mm bucket edge

• Suitable for a 22.5° edge bevel angle

• Compatible with selected K90 replaceable bucket tips

• Designed primarily for wheel-loader and track-loader buckets

• Custom logo, color and export packaging available

• Dimensional and material inspection available before shipment

• Suitable for overseas distributors and bulk GET-parts procurement

Applications

Equipment types:

• Wheel-loader buckets

• Track-loader buckets

• Heavy-duty material-handling buckets

• K90-compatible bucket GET systems

Typical industries:

• Mining

• Quarrying

• Construction

• Aggregate production

• Road building

• Earthmoving

• Sand and gravel handling

Referenced compatible models:

963, 963C, 963D, 973C, 973D, 973K, 950H, 962H, 966G II, 966H, 966K, 966K XE, 966L, 966M, 966M XE, 972G II, 972H, 972K, 972L, 972M, 972M XE and 988H.

Compatibility Notice:
Machine model references are for identification purposes only. Confirm the bucket configuration, adapter number, edge thickness, bevel angle, mounting holes and machine serial number before ordering.
