61LD-00360 Bucket Center Cutting Edge for Hyundai HL740-7 / HL757-7

Full Description

The 61LD-00360 is supplied as an aftermarket bucket center cutting edge referenced to Hyundai Construction Equipment applications. Parts catalogues identify it as a bolt-on center edge used on selected Hyundai HL740-7 and HL757-7 wheel-loader bucket assemblies.

Installed along the center section of the bucket’s lower front edge, this replaceable wear component contacts the working material during loading and digging. Its position distinguishes it from the shorter side cutting edges installed at the outer ends of the same cutting-edge system. The related Hyundai reference 61LD-00370 is identified as a side cutting edge and should not be treated as an equivalent replacement for 61LD-00360.

Professional wear-parts catalogues commonly list 61LD-00360 with reference dimensions of 48.583 inches in length, 11.417 inches in width and 1.000 inch in thickness, approximately 1,234 × 290 × 25–25.4 mm. The reference pattern contains five mounting holes for 3/4-inch plow bolts. Because some retail listings contain different dimensions, buyers should approve an actual measurement sheet or product drawing before production or shipment.

Parts-catalogue information associates the standard 61LD-00360 number with selected earlier serial-number configurations. Later or regional bucket assemblies may specify 61LD-00360BG. The BG-suffix version should be treated as a related, serial-dependent reference rather than an automatically interchangeable number. Compatibility must be checked using the complete machine and bucket information.

The product photograph contains three stacks of yellow-painted loader cutting edges with different lengths and hole patterns. The left-hand blade clearly displays the 61LD-00360 marking and a blue YASSIAN logo. Five countersunk mounting holes are visible on this marked blade. The center and right-hand products do not show a readable 61LD-00360 marking and should not be identified as the same part number without separate confirmation.

Published market weights vary. As no verified weight for the supplied batch is available, unit weight should be confirmed by measurement. Material grade, hardness, heat treatment and manufacturing process must also be confirmed through the quotation, drawing or inspection documents.

This product is intended for construction-machinery parts distributors, importers, wheel-loader repair workshops, mines, contractors and fleet-maintenance buyers. To confirm compatibility, please provide the Hyundai machine model and serial number, bucket assembly number, bucket capacity, old cutting-edge number, overall dimensions, complete five-hole pattern, required quantity and delivery destination.

Key Features

• Aftermarket replacement referenced to Hyundai 61LD-00360

• Center-position cutting edge for selected wheel-loader buckets

• Five-hole bolt-on reference configuration

• Common reference size of approximately 1,234 × 290 × 25 mm

• Reference mounting arrangement for 3/4-inch plow bolts

• Reference applications for selected HL740-7 and HL757-7 configurations

• Visible 61LD-00360 and YASSIAN markings on the photographed left blade

• Suitable for distributor, repair, contractor and fleet-parts procurement

Compatible Machine Models

Reference catalogue applications include:

• Hyundai HL740-7 — selected cutting-edge bucket configurations

• Hyundai HL757-7 — selected cutting-edge bucket configurations

Compatibility depends on the machine serial number, bucket assembly, bucket capacity and cutting-edge arrangement. Later configurations may use 61LD-00360BG. Confirm all information before ordering.

Reference Part Numbers

• Primary Reference: 61LD-00360

• Common Format: 61LD00360

• Confirmed Equivalent or Superseding Number: Not provided

• Related Serial-Dependent Version: 61LD-00360BG

• Related Side Cutting Edge: 61LD-00370 / 61LD-00370BG

• Related Cutting Edge Kit: 61LD-00910 / 61LD-00910BG

• Related Bolt Reference: 61L3-0198

• Related Nut Reference: S206-20100B

Related numbers are not automatically interchangeable and are not assumed to be included.

Applications

• Wheel-loader bucket center cutting-edge replacement

• Bucket lip wear-part maintenance

• Loading and material-handling operations

• Construction and earthmoving equipment maintenance

• Aggregate and quarry fleet parts supply

• Distributor and repair-workshop inventory
