87454487 78-Inch Bucket Cutting Edge for Case/New Holland

Share to:

87454487 78-Inch Bucket Cutting Edge for Case/New Holland

Part Number ： 87454487
Product Type ： Reversible bolt-on bucket cutting edge
Product Status ：Aftermarket replacement part
Brand Reference ： Case Construction / New Holland Construction / CNH
Compatible Equipment ： Selected skid steer and compact track loader buckets
Installation Position ： Lower front edge of a compatible bucket
Nominal Bucket Size ： 78-inch class
Published Overall Length ： 2016.1 mm in dealer catalogs; confirm actual product
Published Width ： 203.2 mm nominal; confirm actual product
Mounting Pattern : 9 holes
Fastener Reference : 5/8"-11 system; confirm against the bucket assembly
Reference Package Weight : Approximately 55 kg

Model:
87454487
Style:
Caterpillar

Availability:



Inquire

Product Description

Product Description

Full Description

The 87454487 cutting edge is an aftermarket bolt-on wear component supplied for compatibility identification against a CNH reference number. Case Construction identifies the reference as a reversible 78-inch bolt-on cutting edge with nine mounting holes.

This type of cutting edge is installed along the lower front edge of a compatible skid steer or compact track loader bucket. It forms the replaceable contact edge used during loading, site preparation, cleanup and material-handling operations. When the exposed working edge becomes worn, a reversible configuration may allow the opposite edge to be used, provided the bucket design, wear condition and installation instructions permit reversal.

Dealer catalogs describe 87454487 as a double-edged cutting edge with a nominal width of 203.2 mm and a published overall length of 2016.1 mm. However, older parts diagrams and the official 78-inch designation also reference approximately 1981 mm. These values may describe different measurement points, such as nominal bucket width and cutting-edge overall length. Buyers should therefore confirm the actual length, width, thickness and hole positions before placing an order.

The reference configuration uses nine mounting holes. Related parts diagrams show a 5/8"-11 carriage or plow-bolt system, but the bolt length, grade, square-seat dimensions and nut reference may vary between assemblies or production periods. Bolts and nuts are not assumed to be included unless they are specifically listed in the quotation.

Catalog applications include selected Case 420, 430 and 440 skid steer loaders; 420CT and 440CT compact track loaders; selected SR240, SR270, SV280, SV300 and SV340 skid steers; and selected TR270, TR310, TR340, TV370, TV380 and TV450 compact track loaders. New Holland references include selected C190, C232, C234, C237, C238 and C245 compact track loaders, together with selected L190, L228, L230 and L234 skid steer loaders.

These machine references do not establish universal fitment. Several different bucket widths, cutting-edge kits and attachment configurations may be available for the same machine. The bucket assembly, serial-number range and complete hole layout remain the controlling compatibility information.

No confirmed one-for-one superseding cutting-edge number was found. The number 434817A1 appears as a related 78-inch cutting-edge kit rather than an equivalent individual cutting edge.

The supplied photograph shows multiple yellow-painted straight cutting edges stacked in two columns and secured with black packaging straps and protective corner pieces. Regularly positioned mounting holes are visible, including square-seat hole profiles. The photograph does not clearly show the part number or an OEM logo.

This listing is intended for distributors, importers, repair companies, contractors, mines and fleet-maintenance buyers. For compatibility checking, provide the machine model, serial number, bucket type, old part number, actual measurements, hole pattern, quantity and delivery destination.
