85999108 89-Inch Bucket Cutting Edge for Case/New Holland

Full Description

The 85999108 cutting edge is a long, straight bolt-on wear component used along the lower front edge of a compatible loader bucket or attachment. CNH parts information identifies this reference as an approximately 89-inch reversible cutting edge with a double-bevel profile and eight mounting holes.

Installed at the bucket’s leading edge, the component forms the replaceable contact surface between the bucket and the material being handled. Depending on the bucket design, it may be used during loading, site preparation, material handling, cleanup and other earthmoving work. The cutting edge is intended to be replaced when wear reaches the applicable service limit.

The reference dimensions are 2250 mm in length and approximately 203–203.2 mm in width. Professional cutting-edge catalogs commonly list a nominal thickness of 19 mm. Because the offered product is an aftermarket replacement, buyers should confirm the actual dimensions, edge profile and hole layout rather than relying only on the part number.

The reference configuration uses eight square mounting holes. CNH parts information associates the system with 5/8"-11 cutting-edge plow bolts. The hole diameter, square-seat dimensions, end spacing and center-to-center distances should be checked before an order is released. Mounting hardware is not assumed to be included unless specifically stated in the quotation.

Parts catalogs associate 85999108 with selected Case and New Holland machines. Referenced groups include 445, 450 and 465 skid steer loaders; 445CT and 450CT compact track loaders; SR250, SV250, SV300, TR320 and TV380 machines; selected New Holland C-series compact track loaders; and several B-series loader backhoes.

In many catalog records, the cutting edge is linked to a particular loader bucket, grapple or optional cutting-edge kit. A machine model appearing in a catalog does not mean that every bucket fitted to that machine uses the same cutting edge. The machine serial number, attachment type and bucket assembly should therefore be checked.

Dealer records identify 85801161 as a previous reference replaced by 85999108. Industry catalogs also associate 85824011 with the same dimensional pattern, but direct interchangeability should be confirmed before it is used as an ordering reference.

The product photograph shows multiple yellow-painted cutting edges arranged in three strapped bundles. YASSIAN markings are visible near one end of the upper pieces. The products have a straight rectangular form, regularly positioned mounting holes and layered beveled edges. No OEM logo or mounting hardware is visible.

This product is intended for parts distributors, importers, equipment repair companies, contractors, mines and fleet maintenance teams. To confirm supply, provide the machine model, serial number, bucket type, old part number, measured dimensions, hole pattern, required quantity and destination.

Key Features

• Aftermarket replacement supplied against reference number 85999108

• Nominal 2250 mm / 89-inch cutting-edge length

• Straight bolt-on configuration

• Double-bevel reference profile

• Reversible reference design

• Eight square mounting holes

• Compatibility checking based on machine, bucket and measured dimensions

Compatible Machine Models

Parts catalogs associate 85999108 with selected configurations of:

Skid Steer Loaders

• 445, 450 and 465

• SR250, SV250 and SV300

Compact Track Loaders

• 445CT and 450CT

• TR320 and TV380

• C185, C190, C232, C238 and C245

• Some selected C327, C332, C334, C337 and C345 configurations may also use this reference

Loader Backhoes

• B90B

• B95, B95B, B95C and B95D

• B100B

• B110, B110B, B110C and B110D

• B115B and selected B115BTC configurations

• LB110

Compatibility depends on the installed bucket or attachment. Confirm the machine serial number, bucket assembly and mounting pattern before ordering.

Reference Part Numbers

• 85801161 — previous reference replaced by 85999108

• 85999108 — main reference covered by this listing

• 85824011 — industry cross-reference with a similar dimensional pattern; interchangeability must be confirmed

Applications

• Loader bucket leading-edge replacement

• Skid steer loader buckets and selected attachments

• Compact track loader buckets and selected attachments

• Loader-backhoe front buckets

• General construction and site preparation

• Aggregate, soil and bulk-material handling

• Equipment and fleet maintenance
