PC100RC Rock Chisel Bucket Tooth – Aftermarket Replacement

Full Description

The PC100RC reference is commonly used in aftermarket catalogs for a rock chisel bucket tooth associated with Komatsu-style PC100 tooth systems. This listing provides a starting point for identifying a replacement tooth and preparing a purchase inquiry. It does not establish compatibility with every excavator carrying a PC100 model designation. The existing bucket assembly and tooth connection must be checked before an order is confirmed.

A bucket tooth forms part of the ground engaging assembly at the front of the bucket. The replaceable tooth fits onto a matching adapter and contacts the material during digging and loading. The tooth pocket, adapter nose and retention arrangement must work together. Selecting a tooth by its outer profile or machine name alone can overlook differences in the connection.

The rock chisel profile is a selection option for excavation involving rocky or compacted material. Its suitability should be assessed against the actual material, operating conditions and bucket configuration. Contractors, quarry operators and maintenance teams should provide application details when requesting a replacement. No service-life, penetration or productivity improvement is specified for this listing.

For compatibility review, start with all markings on the existing tooth and adapter. Provide clear photographs of the complete tooth, both sides, the rear pocket opening and the retention features. Include the machine model, serial number and any bucket identification available. If the bucket has been replaced or modified, describe the current assembly rather than relying only on the original machine specification.

Record dimensions with units and clearly identified reference points. Useful checks include the tooth pocket opening, relevant pocket geometry, pin-hole size and position, and the matching adapter nose. Where pocket depth or seating geometry cannot be measured reliably, provide a drawing or sample. A worn tooth can help identify the system, but distorted surfaces should not be treated as the sole dimensional reference.

Some aftermarket catalogs associate PC100RC with the search reference 20X-70-14160RC. Treat this as a cross-reference lead for review, rather than an unconditional interchangeability statement. A different supplier's PC100RC designation may describe another version. Dimensions, mass, material, hardness, manufacturing route and surface finish should therefore be confirmed against the specification offered for the order.

YASSIAN is a China-based supplier of construction machinery wear parts serving distributors, importers, repair companies and construction customers. For a bulk inquiry, send the required quantity, destination, delivery schedule and any documentation requirements. State whether you need a tooth quotation alone or would like matching retention components reviewed separately. Component inclusion must be identified in the quotation.

Before purchasing, agree the product specification, relevant inspection requirements, packaging, supply scope and delivery terms. Any requested material or hardness documentation should relate to the quoted product or batch. Contact YASSIAN with your part reference and assembly information to begin a compatibility review and receive a quotation.

Key Features

• PC100RC reference for aftermarket bucket tooth sourcing.

• Rock chisel profile identification used in aftermarket catalogs.

• Komatsu-style PC100 tooth-system association, subject to assembly verification.

• Replaceable tooth application on a matching bucket adapter.

• Compatibility review based on markings, photographs and measurements.

• Bulk purchasing inquiries from distributors, importers and maintenance businesses.

Compatible Machine Models

Commonly cataloged for Komatsu-style PC100 tooth systems. Specific machine models and bucket configurations require compatibility review. Confirm the existing tooth, adapter and retention arrangement before ordering.

Reference Part Numbers

Common aftermarket catalog reference for review: 20X-70-14160RC (20X7014160RC). This reference does not establish unconditional interchangeability. Confirm the actual connection and offered specification before accepting a replacement.

Applications

• Replacement sourcing for excavator buckets with a verified matching tooth system.

• Application review for digging in rocky or compacted material.

• Procurement by distributors, importers, repair businesses and construction customers.
