446-1524 Manganese Bronze Circle Blade Wear Strip for Cat Motor Graders

Aftermarket 446-1524 manganese bronze/brass wear strip for selected Cat motor grader blade and moldboard guide assemblies. The U-shaped strip has a reference length of 120 mm and a nominal wall thickness of 9.5 mm. Legacy cross-reference: discontinued part number 5T-8366. Serial-number verification is required.

Full Description

The 446-1524 wear strip is a U-shaped manganese bronze/brass component designed for selected Cat motor grader circle blade and moldboard guide arrangements. It provides a replaceable contact surface that helps maintain component engagement and protects the blade, guide brackets and support structure from direct wear.

The current reference specification identifies a 120 mm overall length and a nominal thickness of 9.5 mm. Its channel-shaped profile surrounds the mating guide area and works with related wear strips, support plates and adjustment shims to maintain the required operating clearance.

Part number 446-1524 is widely cross-referenced in the replacement market to discontinued Cat part number 5T-8366. Because the published fitment ranges for the current and legacy numbers are not identical, final compatibility must be checked using the machine model, serial number, existing part number and component dimensions.

Key Features

• Current reference part number 446-1524

• Legacy cross-reference to discontinued 5T-8366

• Manganese bronze/brass construction

• U-shaped channel profile

• 120 mm reference length

• 9.5 mm nominal thickness

• Replaceable blade-guide wear surface

• Helps protect blade brackets and support components

• Works with adjustment shims to maintain operating clearance

• Suitable for selected Cat motor grader applications

• Designed for distributors, repair workshops and fleet maintenance programs

Confirmed Applications for 446-1524

For selected configurations of:

• Cat 120

• Cat 120H ES

• Cat 120K

• Cat 120K Series 2

• Cat 12H

• Cat 12H ES

• Cat 12H NA

• Cat 12K

• Cat 135H NA

• Cat 140

• Cat 140H

• Cat 140H ES

• Cat 140H NA

• Cat 140K

• Cat 140K Series 2

• Cat 160

• Cat 160K

Additional legacy applications associated with 5T-8366 may be available, but they require machine serial-number and dimensional verification.

Applications

The 446-1524 wear strip is designed to:

• Provide a replaceable contact surface in the blade guide system

• Help maintain engagement between the blade and guide components

• Reduce direct wear on support brackets and structural parts

• Work with steel shims to control operating clearance

• Support smooth blade positioning and adjustment

• Reduce wear-related replacement of larger, higher-cost components

This product is not a grader cutting edge, moldboard blade, drawbar shoe or bucket wear plate.
