106-7129 Straight Bronze Sleeve Bearing for Cat Motor Graders

The 106-7129 sleeve bearing is a straight bronze bushing designed as a replacement component for selected Cat motor grader assemblies. Its cylindrical bearing surface supports controlled rotational or sliding movement while helping maintain alignment between mating components under demanding working conditions.

The bearing has a 2.500-inch inside diameter, a 2.878-inch sleeve outside diameter and a 1.417-inch overall length. An internal groove supports lubricant distribution across the bearing surface, while the design contains no cross holes or external groove.

Depending on the machine model, serial number and parts arrangement, 106-7129 may be used in circle-drive or selected hydraulic cylinder assemblies. Always confirm the part number against the machine serial number and applicable parts catalog before purchase or installation.

Key Features

• Direct replacement reference for part number 106-7129

• Straight sleeve-bearing construction

• Bronze bearing material

• 63.50 mm precision bore

• 73.10 mm sleeve outside diameter

• 35.99 mm overall length

• Internal lubrication groove

• No cross holes

• No external groove

• Designed for demanding motor grader service

• Supports low-speed rotational or sliding movement

• Suitable for maintenance, repair and fleet replacement programs

Applications

Compatible with selected configurations of the following Cat motor graders:

• 12G

• 12H, 12H ES and 12H NA

• 120G

• 120H, 120H ES and 120H NA

• 130G

• 135H and 135H NA

• 140G

• 140H, 140H ES and 140H NA

• 143H

• 160H, 160H ES and 160H NA

• 163H NA

Potential assembly applications include selected circle-drive, sideshift, wheel-lean, steering and scarifier cylinder arrangements. Application varies by serial number and machine configuration.
