CAT Style 195-7096 Wear Plate

CAT Style 195-7096 Wear Plate, CENTER WEAR PLATE, 1957096 PLATE-WEAR Caterpillar parts 988F, 988F II, 990 II, 990H, 992C, 992D, 992G, 992K PLATE, Bolt-on Top Mounted Wear Plate Center for wheel-type loader

Availability:

Our Advantage

Affordable price                                                            ☑ Customized design is Available                     ☑ T/T, L/C or other payment accepted

☑ Fast shipping, Worldwide delivery                               ☑ Quality guaranteed                                         ☑ Bulk discounts for larger orders

Product Description

CAT Style 195-7096 Wear Plate Feature:
Thickness: 25 mm
Thickness: 0.98 in
Length: 16.1 in
End Width: 254 mm
Length: 410 mm
Weight 44.18 lb / 20.04 kg
Caterpillar style 4 bolt center wear plate for a loader; takes 4 – 125 x 500 plow bolts and 4 – 125 hex nuts
Compatible Models
wheel-type loader
992K, 992G, 990 II 988K, 992C, 988F, 992D, 990H, 988F II


Bolt-on top mounted wear plates protect the bevel and top part of the base edge between the adapters where top wear is a concern. They also help protect top adapter strap welds from eroding as the result of abrasive wear. This eliminates adapter/base edge breakage.


Made from through-hardened DH-2 steel, these Cat® Center plates are used with bolt-on half arrow segments to provide complete base edge coverage and reduce weld joint wear. They are designed to deliver optimum strength and wear life comparable to the wear life of the half arrow, reducing maintenance frequency. Top wear plates bolt in place quickly and easily, using longer segment bolts and nuts.


Attributes:
• Tight bolt-on fit reduces part-to-part wear
• Center plate


Applications:
• Moderate- to highly-abrasive, dense material


Equipment type Model
ENGINE – MACHINE 3408; 3408C; 3408E; 3412; 3412D; 3412E; 3508B; C32
WHEEL-TYPE LOADER 988F; 988F II
Typical applications of Bimetallic Wear Plates include Discharge Chutes, Hoppers, Rock Boxes, Excavator Buckets, Loader Buckets, Dragline Buckets, Face Shovel Buckets, Spider Arm Guards on Crushers. 8E8413 D11 Multiple Shank Ripper


Part IDNameSection
1957095PROTECTOR GROUP-EDGEWORK TOOLS
1955077PROTECTOR GROUP-EDGEWORK TOOLS
1957095PROTECTOR GROUP-EDGEWORK TOOLS
1957099PROTECTOR GROUP-EDGEWORK TOOLS
1895189PROTECTOR GROUP-EDGEWORK TOOLS
1895189PROTECTOR GROUP-EDGEWORK TOOLS
2088834PLATE GROUP-WEARWORK TOOLS
1748021PROTECTOR GROUP-EDGEWORK TOOLS
1895189PROTECTOR GROUP-EDGEWORK TOOLS
2755980EDGE-CUTTINGWORK TOOLS


Product Range

Imperial2

Metrics2


                                 End Width (mm): 254

                                 Length (in): 16.1
                                 Length (mm): 410
                                 Thickness (in): 0.98
                                 Thickness (mm): 25
