Bucket Teeth for Sale 1171-00171L Earth Moving Equipment Spare Parts

How do buffer springs absorb shock and reduce vibration

Buffer springs mainly absorb shock and reduce vibration through the following mechanisms to ensure the stable operation of construction machinery:

I. Elastic deformation energy storage and energy release ‌

The core principle of a buffer spring is to absorb the impact kinetic energy ‌ by its own ‌ elastic deformation, convert it into elastic potential energy for temporary storage, and then release the energy ‌ through deformation recovery. For example:

When heavy-duty equipment (such as excavators) is subjected to road impact, the spring compression deformation can absorb a dynamic load of up to ‌12 tons ‌‌, preventing rigid structures from directly bearing destructive impacts.

During the release stage, the potential energy is converted into heat energy for dissipation through the coordinated action of the dampers (such as hydraulic oil friction), thereby suppressing the spring rebound vibration ‌.

⚙️ 2. Youdaoplaceholder1 works in conjunction with the damping system to reduce vibration ‌

The spring acting alone may cause continuous vibration, so it is necessary to combine it with damping elements to form an efficient vibration reduction system

The energy consumed by the damper ‌ : Hydraulic or viscous dampers convert the kinetic energy released by the spring into thermal energy ‌ through internal frictional resistance (such as oil flow), causing the amplitude to rapidly decay. In automotive shock absorbers, the spring buffer rubber (made of rubber) further filters out high-frequency vibrations and reduces the impact ‌ transmitted to the vehicle body.

Optimize the resonant frequency ‌ : By adjusting the spring stiffness (wire diameter, number of turns design) and damping coefficient, avoid the natural frequency of the equipment and prevent resonant amplification of vibration ‌.

III. Youdaoplaceholder1 Key design parameters affect performance ‌

Buffering effect is regulated by multiple factors (see Table 1) ‌ :

Factors ‌ ‌ mechanism of action ‌ ‌ engineering application cases ‌

Material: ‌ High-strength alloy steel enhances fatigue resistance (such as 500,000 cycles ‌). Engine valve springs are durable and impact-resistant

Structural parameter ‌ number of turns increases → energy storage capacity ↑; Increase in wire diameter → stiffness ↑ The multi-stage spring of the crane achieves 30% axial deformation ‌

The installation matching ‌ preload force and Angle affect the uniformity of force distribution. The anti-deviation tooth profile design of the track equipment ‌

️ IV. Youdaoplaceholder2 engineering application scenarios ‌

Extreme working condition protection ‌ : Mining machinery adopts a combination of annular springs and friction devices, which can efficiently consume energy and resist high-frequency vibrations ‌;

Safety redundancy design ‌ : Elastic buffers in aviation weapons provide bidirectional buffering through spring compression, protecting the precise mounting structure ‌.

▶️ animation demonstration: The principle of spring and damper working together

‌ summary ‌

Buffer springs achieve efficient conversion of impact energy through the physical process of "elastic energy storage → damping energy dissipation", combined with material strengthening (such as surface quenching ‌), parameter optimization (stiffness/frequency matching ‌), and system integration (such as hydraulic damping ‌), providing triple guarantees for construction machinery: ‌ impact buffer ‌ (more than 70% decline ‌, ‌ vibration suppression ‌ (to avoid the resonance zone ‌, ‌ structure protection ‌ extend the service life of key components (‌).
