Product Description
7T1645 9 Holes Caterpillar Curved Grader Blade Spare Parts Specifications:
Part name: Grader Blade
Part No: 7T1645, 7T-1645
Machine : Motor Grader
Weight: 78 pounds 35 kg.
Information:
BEVEL ANGLE 22.5
BOLT HOLE SIZE 18 mm
HOLE SPACING 304.8 mm
LENGTH 2131.2 mm
NUMBER OF HOLES 9
THICKNESS 15.9 mm
WIDTH 152.4 mm
Material: Manganese steel, boron steel
Thickness: 13mm; 16mm; 19mm; 25mm.
Width: 152mm and 203mm.
Length: 4=1219mm; 5=1524mm; 6=1828mm; 7=2133mm; 8=2438mm.
Bolts Dia: 3/4; 5/8
Adaptable for most of graders in market, including Komatsu, Caterpillar, Hitachi, Sumitomo, Kato, Daewoo, etc, also could be designed and produced by clients’ drawing.
Mechanical properties of products could reach international standard after quenching and tempering heat treatment.
Thanks to our high quality raw material and professional heat treatment, our products’ wear life and performance of are 15% ~ 20% higher than most of other similar products in market.
Trade Terms: FOB NINGBO.
Payment Terms: 30% prepaid, T/T at the sight of copy of B/L.
Part Number | Measurement (mm) | Description | Brand | Weight(Kgs) |
232-70-12142 | 1828mmX152mmX13mm 5/8″X8 | DBC Grader Blades | Komatsu | 24 |
4T3512 | 1219mmX203mmX25mm 3/4″X9 | DBC Grader Blades | CAT | 45 |
7T1627 | 2438mmX203mmX19mm 3/4″X17 | DBC Grader Blades | CAT | 67 |
7T1625 | 2133mmX203mmX19mm 3/4″X15 | DBC Grader Blades | CAT | 59 |
7T1638 | 1828mmX203mmX19mm 3/4″X13 | DBC Grader Blades | CAT | 50 |
9W2341 | 1524mmX203mmX19mm 3/4″X11 | DBC Grader Blades | CAT | 42 |
9W2339 | 1219mmX203mmX19mm 3/4″X9 | DBC Grader Blades | CAT | 33.5 |
7T1630 | 2438mmX203mmX19mm 5/8″X17 | DBC Grader Blades | CAT | 67 |
7T1623 | 2133mmX203mmX19mm 5/8″X15 | DBC Grader Blades | CAT | 59 |
7T1634 | 1828mmX203mmX19mm 5/8″X13 | DBC Grader Blades | CAT | 50 |
9W2340 | 1524mmX203mmX19mm 5/8″X11 | DBC Grader Blades | CAT | 42 |
9W2338 | 1219mmX203mmX19mm 5/8″X9 | DBC Grader Blades | CAT | 33.5 |
7T1628 | 2438mmX203mmX16mm 3/4″X17 | DBC Grader Blades | CAT | 56 |
7T1624 | 2133mmX203mmX16mm 3/4″X15 | DBC Grader Blades | CAT | 49 |
7T1639 | 1828mmX203mmX16mm 3/4″X13 | DBC Grader Blades | CAT | 42 |
9W2329 | 1219mmX203mmX16mm 3/4″X9 | DBC Grader Blades | CAT | 28 |
7T1631 | 2438mmX203mmX16mm 5/8″X17 | DBC Grader Blades | CAT | 56 |
7T1643 | 2133mmX203mmX16mm 5/8″X15 | DBC Grader Blades | CAT | 49 |
7T1636 | 1828mmX203mmX16mm 5/8″X13 | DBC Grader Blades | CAT | 42 |
Offer for instant purchase has cost one hundred and six dollars, forty-six cents, condition of spare part – aftermarket.
Specifications: weight (lbs) 1. For these characteristics delivery equals fifty-seven dollars, seven cents. Abrasion Resistance 9 Holes Caterpillar Spare Parts Curved Cutting Edge 7T1643
Part number 5D9558 EDGE-CUTTING BORON refers to: Ground engaging, Edges. High Carbon Curved Cutting Edge Grader Blade 9W-2302, 9W2302, 9W2302 High Carbon Curved Motor Grader Blade, 7T1633 Cat Style Curved Double Bevel Grader Blade, Caterpillar style Curved Carbon 9 Holes Grader Blade 7T1645, 7T-1645 7T1645 9 Holes Caterpillar Curved Grader Blade Spare Parts, 7T1643, 7T-1643 CATERPILLAR 84″ CURVED GRADER BLADE
109-3150/4T3512,2C3139,3G1626,3G1627,3G1628,3G2165,3G2166,3G9765,3G9766,3G8016,4T2231,4T2233,
4T2236,4T2237,4T2240,4T2242,4T2244,4T2966/5J6965,4T2967/5J6967,4T2968/5J6971,4T2969/5J6972,4T2970/6J2376,4T2971/6J2375,4T3007/5J6970,4T3032/6J2377,4T3033/6J2374,4T3034/8J5352,4T3035/5J6966,4T3036/5J6973,4T3037/6D4201,4T3511,4T6502/8D7702,4T6508/8D0173,4T6511/8D0226,4T8316,4T8317,4T9603,5B5561,5B5562,5B5563,5B5564,5D9553,5D9554,5D9556,5D9557,5D9558,5D9559,5D9561/4D9922,5D9562,5D9731/5D1163/5D1164,5D9732,6G8623,7D1158,7D1576,7D1577,7D1949,7D4508,7D4509,7T3493/4T2232,4T3494/4T2234,7T3495/4T2235,7T3496/4T2238,7T3497/4T2239,7T3498/4T2241,7T3499/4T2243,8D2786,8D2787,8D2788,8D2789,8J4043,8J7782,8J8980,8J9821,9J3655,9J3656,9J3657,9J3658,9J3659,9J3660,9J3862,9J3863,9J7701,9W1835,9W6252,9W2293,9W2295,9W2297,9W2299,9W2301,9W2303,9W2305,9W2307,9W2294,9W2296,9W2298,9W2230,9W2302,9W2304,9W2306,9W2308,9W2325,7T1640,7T1633,7T1645,7T1632,,9W2326,9W2327,7T1637,7T1626,7T1629,9W2331,7T1642,7T1635,7T1644,9W2336,9W2332,9W2333,9W2334,9W2335,9W2337,9W2309,9W2311,9W2313,9W2315,9W2317,9W2319,9W2321,9W2323,9W2310,9W2312,9W2314,9W2316,9W2318,9W2320,9W2322,9W2324,9W2328,7T1641,7T1636,7T1643,7T1631,9W2329,9W2330,7T1639,7T1624,7T1628,9W2338,9W2340,7T1634,7T1623,7T1630,9W2339, 9W2341,7T1638,7T1625,7T1627,232-70-12142,232-70-12143,232-70-12650,232-70-12651,232-70-52940,232-70-52850,232-70-52970, 232-70-52910,232-870-6310,233-70-12141,233-70-12450,233-870-6120,234-70-12192,234-70-12193,234-70-12250,234-70-12450, 234-70-12510,234-70-12550,234-70-12580,234-70-12640,234-70-12670,234-70-12710,234-70-16130,234-70-16290,234-70-16410, 234-70-16420,234-70-32620,235-70-12140,236-70-22120,237-70-12120,238-70-12220. Motor Grader Edge Cutting 5D-9556 5D9556, 7T1634, 7T-1634 Caterpillar Style Grader Curved Double Bevel Blade
