75241478 Curved Motor Grader End Bit for Case/New Holland

Full Description

This product is an aftermarket curved motor grader end bit supplied against reference part number 75241478. The official New Holland Construction parts listing describes 75241478 as a cutting edge end bit. It belongs to the grader blade wear-parts system and is installed at the outer end of a compatible moldboard or cutting-edge assembly.

The end section of a grader blade works close to the shoulder of the cutting path and is exposed to abrasive soil, aggregate and impact from embedded material. An end bit provides a replaceable wear surface in this area and helps maintain the working outline of the blade. The exact operating position, left- or right-hand arrangement and mounting direction must be checked against the applicable blade assembly before installation.

Dealer parts catalogs associate reference 75241478 with selected Case and New Holland grader configurations, including members of the 845/845B and 865/865B families, as well as selected F140/F140B/RG140.B, F170/F170B/RG170.B and F200/F200B/RG200.B configurations. Some industry diagrams also associate the number with selected 885/885B machines. These references cover different drive versions and 12-, 13- or 14-foot blade assemblies, so the machine family alone is not sufficient to establish compatibility.

The photographed products are yellow-painted curved plates. Five pieces are shown, and the visible pieces have one row of six recessed mounting holes. The number 75241478 is marked on several pieces. No physical OEM logo is visible. The YASSIAN name appearing on the image is the supplier’s image branding rather than an OEM marking on the product.

Catalog records indicate a service-number sequence from previous reference 75266798 to 75241478 and then to replacement reference 75266800. This sequence is useful for cross-reference research but does not prove that every version is dimensionally interchangeable in every blade assembly. Buyers should confirm the latest service replacement with their machine serial number and parts book.

Published dimensional and weight data are inconsistent. For this reason, dimensions, net weight, material grade, hardness and heat-treatment details are not stated as confirmed specifications. Before production or shipment, compatibility should be checked using the old part number, machine identification, moldboard length, mounting-hole layout and measured dimensions.

This product is intended for distributors, importers, grader maintenance companies, mines, contractors and fleet workshops sourcing replacement ground-engaging components. For bulk inquiries, provide the required quantity and destination together with the technical identification information. Packing method, inspection requirements and delivery schedule can then be confirmed in the quotation.

Key Features

• Aftermarket replacement supplied against reference number 75241478

• Curved end-bit profile for compatible motor grader moldboard assemblies

• Six mounting holes visible on the photographed parts

• Part number marked on multiple photographed pieces

• Referenced for selected Case and New Holland grader configurations

• Previous and superseding references available for cross-reference checking

• Compatibility reviewed against machine and blade information before order confirmation

Compatible Machine Models

Parts catalogs reference 75241478 for selected configurations in these families:

• Case 845 and 845B

• Case/New Holland 865 and 865B

• F140, F140B and RG140.B

• F170, F170B and RG170.B

• F200, F200B and RG200.B

• Selected 885 and 885B configurations may also use this reference

Compatibility is not confirmed by model name alone. Verify the machine serial number, blade assembly, moldboard length, installation side and mounting dimensions.

Reference Part Numbers

• 75266798 — previous or superseded reference listed in dealer records

• 75241478 — product reference covered by this listing

• 75266800 — listed service replacement for 75241478

Confirm the current replacement direction and dimensional compatibility before ordering.

Applications

• Motor grader road construction and maintenance

• Site preparation and surface grading

• Mine and quarry haul-road maintenance

• Shoulder shaping and ditch-related grading

• Replacement of worn grader moldboard end components
