131-3736 Tie Rod Socket for Cat Motor Graders

The 131-3736 tie rod socket is an aftermarket replacement component for selected Cat motor grader steering systems. Caterpillar identifies reference part number 131-3736 as a 1-14-2A tie rod socket used with the steering cylinder and steering linkage.

The socket connects with the rod ends of the steering control arms and provides a secure, articulated connection within the steering system. During operation, this component is exposed to steering torque, repeated direction changes, vibration and impact loads. Accurate dimensions, correct thread geometry and dependable material quality are therefore important for proper installation and steering performance.

Published reference dimensions are 8.3 inches in overall length, 5.25 inches in overall width and 2.6 inches in overall height. The reference material is carbon steel, and the component incorporates external shaft threads.

The 131-3736 socket is associated primarily with selected Cat 12, 120, 135, 140, 143, 160 and 163 motor grader models. Because equipment configuration and serial-number breaks may affect compatibility, the machine model, serial number and original part number should be checked before ordering.

This product is supplied as an aftermarket replacement. Caterpillar, Cat, machine model designations and part numbers are used for identification and compatibility reference only.

Key Features

• Aftermarket replacement for reference part number 131-3736

• Tie rod socket for motor grader steering systems

• Carbon-steel construction

• External shaft thread design

• Connects with steering control arm rod ends

• Supports controlled steering linkage articulation

• Reference dimensions based on published Caterpillar data

• Suitable for grader steering repair and maintenance

• Dimensional inspection available before shipment

• Bulk supply and customized export packaging available

Application and Compatible Models

The 131-3736 tie rod socket is used in the steering system of selected Cat motor graders.

Published Caterpillar compatibility includes:

• Cat 12G

• Cat 12H, 12H ES and 12H NA

• Cat 12K

• Cat 120 and 120 GC

• Cat 120H, 120H ES and 120H NA

• Cat 120K and 120K Series 2

• Cat 135H and 135H NA

• Cat 140 and 140 GC

• Cat 140G

• Cat 140H, 140H ES and 140H NA

• Cat 140K and 140K Series 2

• Cat 143H

• Cat 160

• Cat 160H, 160H ES and 160H NA

• Cat 160K

• Cat 163H and 163H NA

Model listings provide general compatibility guidance only. Always verify the part against the machine serial number and the applicable parts catalog.

Typical Applications

• Road construction

• Road maintenance

• Fine grading

• Site preparation

• Mining haul-road maintenance

• Municipal infrastructure

• Motor grader steering overhaul

• High-hour equipment maintenance
