11142033 Bucket Heel Wear Plate for Volvo L90/L110/L120

Full Description

This product is an aftermarket bucket heel or rear wear plate cross-referenced to Volvo Construction Equipment part number 11142033. Volvo CE and specialist ground-engaging-tool catalogs identify this reference as a wear plate used in bucket applications. It should not be confused with a conventional front cutting edge or bolt-on center blade.

The wear plate is installed on the underside or heel area of a compatible bucket. This area can be exposed to sliding contact with soil, aggregate and other handled materials as the bucket fills, carries and discharges its load. The replaceable plate provides a wear surface between the working material and the bucket structure. Its exact mounting position and orientation depend on the bucket design and arrangement.

Several industry catalogs associate reference number 11142033 with selected Volvo L90, L110 and L120 wheel loaders. More detailed bucket component references include certain L90C, L90D, L90E and L120B, L120C, L120D and L120E configurations. Machine model alone does not confirm fitment because the required plate may vary with the serial-number range, bucket type, bucket width, base edge and wear-part arrangement.

Common catalog dimensions are approximately 550 mm in length, 310 mm in width and 30 mm in thickness. The commonly referenced configuration uses four mounting holes and 3/4-inch or corresponding M20-series hardware. These dimensions and mounting details are reference information only. Supplier catalogs show variations in thickness, hole design and weight, so the actual plate must be checked before production or shipment.

The photographed product consists of multiple dark gray plate-type wear parts stacked and secured for handling. Large semicircular or U-shaped relief openings are visible, together with smaller side slots. The products are secured using black straps, metal buckles and corner protectors. No OEM logo is visible on the product itself.

This product is intended for distributors, importers, mining operations, repair companies and contractors sourcing replacement bucket wear parts. For compatibility checking, buyers should provide the requested part number, machine model, serial number, bucket type or arrangement number, existing-plate measurements and clear photographs. Actual material, hardness, heat treatment, weight, coating, included components and packaging requirements must be confirmed in the quotation or approved technical document.

Key Features

• Aftermarket replacement cross-referenced to 11142033

• Bucket heel or rear wear-plate configuration

• Designed for compatible bucket underside and heel areas

• Large U-shaped relief profile

• Commonly referenced for selected Volvo L90, L110 and L120 loaders

• Common four-hole mounting configuration, subject to confirmation

• Compatibility checked against machine and bucket information

• Suitable for replacement-part and bulk procurement enquiries

Compatible Machine Models

Common industry references associate 11142033 with selected configurations of:

• Volvo L90

• Volvo L110

• Volvo L120

Some component catalogs also reference L90C/D/E and L120B/C/D/E bucket arrangements. Compatibility must be verified using the machine serial number, bucket type, bucket arrangement, dimensions and mounting-hole layout.

Reference Part Numbers

• 11142033 — principal Volvo reference

• VOE 11142033 — common Volvo reference format

• VOE11142033 — common no-space format

• 11142033-7 — catalog reference format

Supplier-specific numbers should not be treated as universal equivalents without technical verification.

Applications

• Wheel loader bucket heel protection

• Bucket underside wear protection

• Replacement of worn rear wear plates

• Earthmoving and material-handling buckets

• Construction, quarry and mining maintenance

• Fleet and repair-workshop replacement programs
