Ore Mining Machine Parts Wear Bar

Ore Mining Machine Parts Wear Bar, Bi-metallic Wearing Bar, standard White Iron Wear Bar, 700HB 63HRC White Iron laminated wear bars for wear mining protection, Weldable Domite wear bars, anti-wear material wear bars and blocks, Tungsten Carbide Bars for Wear Parts China supplier

Availability:

Our Advantage

Affordable price                                                            ☑ Customized design is Available                     ☑ T/T, L/C or other payment accepted

☑ Fast shipping, Worldwide delivery                               ☑ Quality guaranteed                                         ☑ Bulk discounts for larger orders

Product Description

Ore Mining Machine Parts Wear Bar – Wear bar is a combination of high chromium (700 brunell) white iron bonded to a mild steel weldable backing plate. Wear bars and blocks are available in thicknesses ranging from 25mm to 100mm, widths from 25mm to 300mm wide and in varying lengths.Popular for use in rock box protection, impact areas and transfer points, bars can be provided with Nelson studs with size and and location to suit.


Available in a wide range of sizes, can be used in a combination of our standard lengths to create layouts and patterns. Perfect for corners, edges and hard to reach places, use Bimetallic Wear Bar and Blocks wherever you need impact and wear resistance.
Wear Bars are available in thicknesses ranging from 25mm to 100mm, widths from 25mm to 300mm wide and in varying lengths. They can be stud bolted to suit fitment needs. They offer superior wear life when compared to conventional alloys such as manganese steel, Ni-hard, Q&T bars and clad overlay strips.
wearing bar Wear Bars offer a cost effective solutions to wear problems.


Made of the lamination of chrome moly white iron bonded to a mild steel backing plate, the Wear bars are great time savers, with the ability to patch areas on machinery and equipment to help them last longer, reduce the downtime and increase productivity.


The chrome-moly white iron with finished minimum hardness of 63HRC or 700 BHN, delivers maximum abrasion protection, while the steel backing plate absorbs high impact and facilitates ease of fitting and use.
The bonding shear strength is over 30,500 psi (or 210 Mpa) and will not separate.
Wear bar offer superior wear life when compared to conventional alloys such as manganese steel,Ni-hard and clad overlay strips.


Product Range

Imperial2

Metrics2


Ore Mining Machine Parts Wear Bar (1)










Wear Bars Drawing

Part No. Size A(mm) B(mm) C(mm) D(mm) E(mm) Unit Weight(kgs)
DLP919 200X25X25 200 25 15 10 25 1.0
DLP1191 300X25X25 300 25 15 10 25 1.5
DLP200 102X33X33 102 33 25 8 33 0.9
DLP515 195X25X30 195 25 20 10 30 1.1
DLP1059 95X25X30 95 25 20 10 30 0.6
DLP4 300X38X33 300 38 25 8 33 3.0
DLP295 153X38X33 153 38 25 8 33 1.5
DLP658 240X40X38 240 40 22 16 38 2.9
DLP508 190X50X30 190 50 20 10 30 2.2
DLP201 432X50X46 432 50 34 12 46 7.8
DLP125 230X50X50 230 50 38 12 50 4.5
DLP201A 432X50X50 430 50 38 12 50 8.5
DLP369 210X50X50 210 50 38 12 80 4.1
DLP452 254X50X50 254 50 40 10 50 5.0
DLP453 294X50X50 294 50 40 10 50 5.8
DLP1101 150X50X50 150 50 40 10 50 2.9
DLP2230 600X50X50 600 50 38 12 50 11.8
DLP270 254X51X20 254 51 12 8 20 2.0
DLP271 203X51X20 203 51 12 8 20 1.6
DLP337 127X51X48 127 51 38 10 48 2.4
DLP965 250X60X20 250 60 12 8 20 2.4
DLP205 279X75X37 279 75 25 12 37 6.1
DLP184 150X75X39 150 75 29 10 39 3.4
DLP569 200X75X39 200 75 29 10 39 4.6
DLP528 150X75X50 150 75 40 10 50 4.4
DLP619 150X75X600 150 75 50 10 60 5.3
DLP450 294X80X50 294 80 38 12 50 9.2
DLP451 194X80X50 194 80 38 12 50 6.1
DLP392/20 241X100X58 241 100 38 20 58 11.0
DLP2110 300X150X60 300 150 48 12 60 21.1
